MODEL : SwitchUPS ¥â 2200 Specification



Power Capacity(VA) ¿ë·® 2200(1440w)
Topology ¹æ½Ä Synthetic power Conversion UPS
Isolation transformer
Àý¿¬º¯¾Ð±â
Provides a galvanic isolation while operating on the inverter operating
Recharge time (normal)
ÃæÀü½Ã°£
8 hours
Typical transfer time with load 2msec(Synthetic power On-line UPS)

  Input Specification

Nominal input voltage and Frequency range
ÀÔ·ÂÀü¾Ð¿¡ ´ëÇÑ ÀϹݻçÇ×
1 phase 200/220/230(user's require) Voltage ¡¾20 % / Auto Frequency 50/60 HZ ¡¾5%

  Output Specification

Nominal output voltage
Ãâ·ÂÀü¾Ð
1 phase 200/220/230 Dip switch selectable
Output voltage regulation (AutoBoost & AutoTrim) ÀÚµ¿Àü¾Ð±â´É On line3 %
Output voltage waveform Ãâ·ÂÆÄÇü Sine wave
Load crest factor supported (c.f) up to 5 : 1
Power factor tolerance Loads with 0.5 to 1.0 power factor
Efficiency inverter at full load ÀιöÅÍ È¿À² ¡µ95 %
Audible noise
(front 1.5m away)
40 dB
Overload capacity Up to 110% for 10 seconds then transfer to inverter
Internal power distribution unit(PDU) 2 plugs

  Feature

Surge Suppression and Noise filtering Yes
User serviceable
(SNMP Service)
Option (QuickSNMP & Others)

  Indicators, Interface & control

LED Indicators Load level(25-100%), Battery level(25-100%), AutoBoost & AutoTrim, Inverter, Battery Abnormal, Alarm, Input voltage level(5 grade )
Power cord Yes
Intelligent serial interface & SNMP Yes

  Others

Battery type ¹èÅ͸® Á¾·ù Lead-acid maintenance free
Battery voltage & cell 12v 3cell (DC 36v)
Individual voltage & current monitoring Self diagnostic, replace battery warning indicator
Method of replacement
¹èÅ͸® ±³Ã¼ ¹æ¹ý
Hand plug compatible & hot swappable
Dimension ´ÜÀ§:mm (H310*W240*D463.2)
Weight 25.9Kg
On site service Optional
¡¡

MODEL : SwitchUPS ¥â 2200


SwitchUPS ¥â 1000º¸´Ù Á»´õÅ« ¿ë·®°ú
¹é¾÷½Ã°£À» ¿øÇÏ½Ã´Ù¸é ¹Ù·Î ¥â 2200À»
¼±ÅÃÇغ¸½Ê½Ã¿À, 2200DESK º¸´Ù Àú·ÅÇÑ
°¡°Ý¿¡ µ¿±Þ ¼º´ÉÀ» üÇè ÇÏ½Ç ¼ö ÀÖ½À´Ï´Ù.

¼ÒºñÀÚ°¡ : 1,600,000
